LED XQD-S4015 DMX

Model XQD-S4015 DMX
Diamension 40mm*13mm*15mm
Application indoor / outdoor
Weight about 14g
Shell material PC
Max qty each chain 100PCS / string
Center distance 10CM minimum
Lifespan 50000 hours
Protection parameters
Waterproof rating IP67
Shell flame resistance V-0
Anti-UV grade 4
Salt spray test Resistance to salt spray
Impact resistance IK10
Electrical safety level Class III
Safety certification CE FCC RoHS
Working temperature -40℃-55℃
Optical parameters
:LED color RGB
Beam angle 120°
Color resolution 3x16bit
Chip type 5050
Electrical parameters
Working voltage DC12V
Rated power 0.72W
Supporting system
Control system DMX512 / Serial SPI
Power system DC12V
